All fluid contact materials in this pump are FDA-Compliant and
meet
the United States Code of Federal Regulations (CFR) Title 21,
Section 177 or are of a corrosion resistant grade Stainless Steel.
The fluid cap and manifold are made of stainless steel (SUS316) .
And their finish has mechanical polishing (finish Ra0.8) and
electronic
polishing optional.
Self-empty flow channel design is good for draining the residual
|
Item
|
FD50-XXXX-X
|
FD64-XXXX-X
|
FD77-XXXX-X
|
FD91-XXXX-X
|
|
Connection Size
|
1″
|
2″
|
2 1/2″
|
3″
|
|
Allowable Air Pressure
|
120 PSI
|
120 PSI
|
120 PSI
|
120 PSI
|
|
Outlet Liquid Pressure
|
0–1.4 MPa
|
0–1.4 MPa
|
0–1.4 MPa
|
0–1.4 MPa
|
|
Max. Flow Rate (lpm)
|
178 lpm
|
340 lpm
|
662 lpm
|
880 lpm
|
|
Displacement per Cycle (L)
|
0.76
|
2.65
|
3.4
|
7.27
|
|
Max. Dry Suction Lift (m)
|
6.1
|
5.3
|
5.6
|
4.5
|
|
Max. Particle Size (mm)<br>Ball Valve
|
4.8 mm
|
8 mm
|
9.5 mm
|
12.5 mm
|
|
Max. Particle Size (mm)<br>Check Valve
|
19.4 mm
|
32 mm
|
38 mm
|
50 mm
|
|
Weight (kg)
|
18
|
32
|
47
|
71.5
|
|
Diaphragm Material
|
Service Life
|
Wear Resistance
|
Chemical Compatibility
|
Thermal Stability
|
Min. Temperature
|
Max. Temperature
|
|
PTFE
|
+
|
+
|
+
|
+
|
40℉/4.4℃
|
220℉/104℃
|
|
Santoprene
|
+
|
+
|
√
|
√
|
-40℉/-40℃
|
225℉/107.2℃
|
|
Hytrel
|
+
|
+
|
√
|
√
|
32℉/0℃
|
175℉/79.4℃
|
|
Viton
|
X
|
!
|
+
|
+
|
-40℉/-40℃
|
350℉/176.6℃
|
|
NBR
|
+
|
√
|
!
|
!
|
10℉/-12℃
|
180℉/82℃
|
